Cracking the Code: Navigating VMware’s Lack of API Documentation for App Volumes – One Victory at a Time

Posted by

childebrandt42

·

, , , ,

Have you ever wondered what all the App Volumes APIs are? Well not all, but way more than VMware has in their documentation.

Over the last few years, I have collected a few App Volumes API calls that are not listed. So figured it was time to share all of them in one place.

Below are all the commands that I have found to date. There might be some more that I am missing but as of this moment this is them. If you want Reference on how to find them for yourself, please look at my last blog post:

Blog Post here!

This code is also stored in GitHub HERE.

<#

.SYNOPSIS

    Powershell Code for App Volumes APIs

.DESCRIPTION

    Detailed example of how to use the App Volumes APIs and code

.NOTES

    Version:          1.0.0

    Author:           Chris Hildebrandt

    twitter:          @childebrandt42

    Date Created:     1/1/2024

    Date Updated:     1/1/2024

#>



################################################################################################################################

#--------------------------------------------Connect to App Volumes Server-----------------------------------------------------#

################################################################################################################################



# Server Address

$AppVolServer = "AppVol.chrislab.local"



# Import Creds from Creds manager

$Creds = Get-StoredCredential -Target "Chris@chrislab.local"



# Set Up Creds Header for App Volumes

$RESTAPIUser = $Creds.UserName

$RESTAPIPassword = $Creds.GetNetworkCredential().password



$AppVolRestCreds = @{

    username = $RESTAPIUser

    password = $RESTAPIPassword

}



# Create your App Volumes Session

$AppVolServerRest = Invoke-RestMethod -SessionVariable SourceServerSession -Method Post -Uri "https://$AppVolServer/cv_api/sessions" -Body $AppVolRestCreds



################################################################################################################################

#----------------------------------------------------Random Commands-----------------------------------------------------------#

################################################################################################################################



# Get - - Version

Invoke-RestMethod -WebSession $SourceServerSession -Method Get -Uri "https://$AppVolServer/cv_api/version"



# Get - - AD Settings

Invoke-RestMethod -Websession $SourceServerSession -Method Get -Uri https://$AppVolServer/cv_api/ad_settings





################################################################################################################################

#-----------------------------------------Inventory Tab on App Volumes Server--------------------------------------------------#

################################################################################################################################



#______________________________________________________________________________________

# Applications



# Get - Applications

Invoke-RestMethod -WebSession $SourceServerSession -Method Get -Uri "https://$AppVolServer/app_volumes/app_products"



# Get - Application Packages

# You will need to get Application ID from the Applications command from above.

$ProductID = $Product.id

Invoke-RestMethod -WebSession $SourceServerSession -Method Get -Uri "https://$AppVolServer/app_volumes/app_products/$ProductID/app_packages?include=app_markers"



# Get - Application Assignments

# You will need to get Application ID from the Applications command from above.

$ProductID = $Product.id

Invoke-RestMethod -WebSession $SourceServerSession -Method Get -Uri "https://$AppVolServer/app_volumes/app_products/$ProductID/assignments?include=entities"



# Put - Set App Package as Current

# You will need to get Application ID from the Applications for this we will use $ProductID and you will need Package ID from Packages for this we will use $AppPackageID

Invoke-RestMethod -WebSession $SourceServerSession -Method put -Uri "https://$AppVolServer/app_volumes/app_products/$ProductID/app_markers/CURRENT?data%5Bapp_package_id%5D=$AppPackageID"



# Delete - Remove Application

# You will need to get Application ID from the Applications for this we will use $ProductID

Invoke-RestMethod -WebSession $SourceServerSession -Method Delete -Uri "https://$AppVolServer/app_volumes/app_products/$ProductID"



#______________________________________________________________________________________

# Packages



# Get - Packages

Invoke-RestMethod -WebSession $SourceServerSession -Method get -Uri "https://$AppVolServer/app_volumes/app_packages?include=app_markers%2Clifecycle_stage%2Cbase_app_package%2Capp_product"



# Get - Package Programs

# You will need o get App Package ID from the Packages command.

$AppPackageID = $AppPackage.id

Invoke-RestMethod -WebSession $SourceServerSession -Method Get -Uri "https://$AppVolServer/app_volumes/app_packages/$AppPackageID/programs"



# Get - Package Opperating Systems

# You will need o get App Package ID from the Packages command.

$AppPackageID = $AppPackage.id

Invoke-RestMethod -WebSession $SourceServerSession -Method Get -Uri "https://$AppVolServer/app_volumes/app_packages/$AppPackageID/operating_systems"



# Get - Package Storage Locations

# You will need o get App Package ID from the Packages command.

$AppPackageID = $AppPackage.id

Invoke-RestMethod -WebSession $SourceServerSession -Method Get -Uri "https://$AppVolServer/app_volumes/app_packages/$AppPackageID/files"



# Get - Package Application Links

# You will need o get App Package ID from the Packages command.

$AppPackageID = $AppPackage.id

Invoke-RestMethod -WebSession $SourceServerSession -Method Get -Uri "https://$AppVolServer/app_volumes/app_packages/$AppPackageID/app_links?"



# Get - Lifecycle List

Invoke-RestMethod -WebSession $SourceServerSession -Method Get -Uri "https://$AppVolServer/app_volumes/lifecycle_stages"



# Put - Set App Package Lifecycle Stage

# To set Lifecycle Stage you need a few things. App Package ID and for this we are using $AppPackageID, and the lifecycle stage ID you want to set, for this we are using $LifecycleID.

Invoke-RestMethod -WebSession $TargetServerSession -Method put -Uri "https://$AppVolServer/app_volumes/app_packages/$AppPackageID?data%5Blifecycle_stage_id%5D=$LifecycleID"



#______________________________________________________________________________________

# Programs



# Get - Programs

Invoke-RestMethod -WebSession $SourceServerSession -Method get -Uri "https://$AppVolServer/app_volumes/app_programs"



#______________________________________________________________________________________

# Assignments



# Get - Assignments

Invoke-RestMethod -WebSession $SourceServerSession -Method get -Uri "https://$AppVolServer/app_volumes/app_assignments?include=entities,filters,app_package,app_marker"



# Post - Unassign Users or Groups

# Will need an Assignment ID for what you want to remove, for this we are using $AssignmentID

Invoke-RestMethod  -WebSession $SourceServerSession -Method Post -Uri "https://$AppVolServer/app_volumes/app_assignments/delete_batch?ids%5B%5D=$AssignmentID"



# Post - Assign User or Group

# This one is fun. Requires some prework we need to create a Body for this. But will require a few things

# You will need Product ID so for this we are using $ProductID

# You will need User or Group ID for this we are using $UserGroupID

# You will need to know if 'User' or 'Group' for this we are going ot Set $Type = 'User'

# If you want to set user to "Package" you will need to know package ID, if not that needs to be set to null, and if you do you need to set "Marker to null.

# If you want to set user to "Current" you need to set the value of app_package to null, and then set app_marker_name to "CURRENT" for this we are using $Marker = "CURRENT"

# You will need to know the Application ID you plan to use, so for this we are going to use $ProductID

$AssignmentJsonBody = "{""data"":[{""app_product_id"":$ProductID,""entities"":[{""path"":""$UserGroupID"",""entity_type"":""$Type""}],""app_package_id"":null,""app_marker_name"":""$Marker"",""app_marker_id"":$ProductID}]}"

# now you can run the following command after you build the body

Invoke-RestMethod  -WebSession $SourceServerSession -Method Post -Uri "https://$AppVolServer/app_volumes/app_assignments" -Body $AssignmentJsonBody -ContentType 'application/json'



#______________________________________________________________________________________

# Attachments



# Get - Assignments App Markers

# You will need to get Assignment ID and enter into command

$AssignmentID = $Assignment.id

Invoke-RestMethod -WebSession $SourceServerSession -Method Get -Uri "https://$AppVolServer/app_volumes/app_packages/$AssignmentID/programs"



# Get - App Attachments

Invoke-RestMethod -WebSession $SourceServerSession -Method Get -Uri "https://$AppVolServer/app_volumes/app_attachments"



# Get - Writeable Volumes

Invoke-RestMethod -WebSession $SourceServerSession -Method Get -Uri "https://$AppVolServer/app_volumes/writables"



################################################################################################################################

#-----------------------------------------Directory Tab on App Volumes Server--------------------------------------------------#

################################################################################################################################



#______________________________________________________________________________________

# Online Users



# Get - Online Users

Invoke-RestMethod -WebSession $SourceServerSession -Method Get -Uri "https://$AppVolServer/cv_api/online_entities"



#______________________________________________________________________________________

# Users



# Get - Users

Invoke-RestMethod -WebSession $SourceServerSession -Method Get -Uri "https://$AppVolServer/cv_api/users"

# if you want to filter out deleted

Invoke-RestMethod -WebSession $SourceServerSession -Method Get -Uri "https://$AppVolServer/cv_api/users?deleted=hide"



#______________________________________________________________________________________

# Computers



# Get - Computers

Invoke-RestMethod -WebSession $SourceServerSession -Method Get -Uri "https://$AppVolServer/cv_api/computers"

# if you want to filter out deleted

Invoke-RestMethod -WebSession $SourceServerSession -Method Get -Uri "https://$AppVolServer/cv_api/computers?deleted=hide"



#______________________________________________________________________________________

# Groups



# Get - Groups

Invoke-RestMethod -WebSession $SourceServerSession -Method Get -Uri "https://$AppVolServer/cv_api/groups"

# if you want to filter out deleted

Invoke-RestMethod -WebSession $SourceServerSession -Method Get -Uri "https://$AppVolServer/cv_api/groups?deleted=hide"



#______________________________________________________________________________________

# Organizational Units



# Get - OU's

Invoke-RestMethod -WebSession $SourceServerSession -Method Get -Uri "https://$AppVolServer/cv_api/org_units"

# if you want to filter out deleted

Invoke-RestMethod -WebSession $SourceServerSession -Method Get -Uri "https://$AppVolServer/cv_api/org_units?deleted=hide"



################################################################################################################################

#--------------------------------------Infrasctucture Tab on App Volumes Server------------------------------------------------#

################################################################################################################################



#______________________________________________________________________________________

# Machines



# Get - Machines

Invoke-RestMethod -WebSession $SourceServerSession -Method Get -Uri "https://$AppVolServer/cv_api/machines"

# if you want to filter out deleted

Invoke-RestMethod -WebSession $SourceServerSession -Method Get -Uri "https://$AppVolServer/cv_api/machines?deleted=hide"



#______________________________________________________________________________________

# Storages



# Get - Storages

Invoke-RestMethod -WebSession $SourceServerSession -Method Get -Uri "https://$AppVolServer/cv_api/storages"

# if you want to filter out deleted

Invoke-RestMethod -WebSession $SourceServerSession -Method Get -Uri "https://$AppVolServer/cv_api/storages?deleted=hide"



# Put - Mark Data Store as Non-Attachable

# You will need the DataStore ID to mark, for this example we are going to use varivle $StorageID

Invoke-WebRequest -WebSession $SourceServerSession -Method put -Uri "https://$AppVolServer/cv_api/storages/mark_attach_action?ids%5B%5D=$StorageID&mark_attach_action=no_attach"



#______________________________________________________________________________________

# Storage Groups



# Get - Storage groups

Invoke-RestMethod -WebSession $SourceServerSession -Method Get -Uri "https://$AppVolServer/cv_api/storage_groups"



# Post - Rescan Storage Group

# You will need the Storage Group ID to mark, for this example we are going to use varivle $GroupID

Invoke-RestMethod -WebSession $SourceServerSession -Method Post -Uri "https://$AppVolServer/cv_api/storage_groups/$GroupID/rescan"



# Post - Import Apps for Storage Group

# You will need the Storage Group ID to mark, for this example we are going to use varivle $GroupID

Invoke-RestMethod -WebSession $SourceServerSession -Method Post -Uri "https://$AppVolServer/cv_api/storage_groups/$GroupID/import"



# Post - Replicate the Storage Group

# You will need the Storage Group ID to mark, for this example we are going to use varivle $GroupID

Invoke-RestMethod -WebSession $SourceServerSession -Method Post -Uri "https://$AppVolServer/cv_api/storage_groups/$GroupID/replicate"



#______________________________________________________________________________________

# Instances



# Get - Instances

Invoke-RestMethod -WebSession $SourceServerSession -Method Get -Uri "https://$AppVolServer/app_volumes/manager_instances/related?api_version=4050"



#______________________________________________________________________________________

# Pending Actions



# Get - Pending Actions

Invoke-RestMethod -WebSession $SourceServerSession -Method Get -Uri "https://$AppVolServer/cv_api/jobs/pending"



#______________________________________________________________________________________

# Jobs



# Get - Jobs

Invoke-RestMethod -WebSession $SourceServerSession -Method Get -Uri "https://$AppVolServer/cv_api/jobs"



#______________________________________________________________________________________

# Activity Logs



# Get - Activity Logs

Invoke-RestMethod -WebSession $SourceServerSession -Method Get -Uri "https://$AppVolServer/cv_api/activity_logs"



#______________________________________________________________________________________

# System Messages



# Get - System Messages

Invoke-RestMethod -WebSession $SourceServerSession -Method Get -Uri "https://$AppVolServer/cv_api/system_messages"



#______________________________________________________________________________________

# Troubleshooting Archives



# Get - Troubleshooting Archives

Invoke-RestMethod -WebSession $SourceServerSession -Method Get -Uri "https://$AppVolServer/cv_api/troubleshooting_archive"



#______________________________________________________________________________________

# Licnese Information



# Get - License Information

Invoke-RestMethod -WebSession $SourceServerSession -Method Get -Uri "https://$AppVolServer/cv_api/license"



#______________________________________________________________________________________

# Active Directory Domains



# Get - Active Directory Domains

Invoke-RestMethod -WebSession $SourceServerSession -Method Get -Uri "https://$AppVolServer/cv_api/ldap_domains"



#______________________________________________________________________________________

# Administrator Roles



# Get - Administrator Roles

Invoke-RestMethod -WebSession $SourceServerSession -Method Get -Uri "https://$AppVolServer/cv_api/group_permissions"



#______________________________________________________________________________________

# Machine Managers



# Get - Machine Managers

Invoke-RestMethod -WebSession $SourceServerSession -Method Get -Uri "https://$AppVolServer/cv_api/machine_managers"



#______________________________________________________________________________________

# License Servers

# Get - License Information

Invoke-RestMethod -WebSession $SourceServerSession -Method Get -Uri "https://$AppVolServer/cv_api/license"



#______________________________________________________________________________________

# Storage



# Get - Storage

Invoke-RestMethod -WebSession $SourceServerSession -Method Get -Uri "https://$AppVolServer/cv_api/storages"



# Post - Data Store Rescan

Invoke-RestMethod -WebSession $SourceServerSession -Method Post -Uri "https://$AppVolServer/cv_api/datastores/rescan"



#______________________________________________________________________________________

# App Volumes Manager Servers



# Get - App Volumes Manager Servers

Invoke-RestMethod -WebSession $SourceServerSession -Method Get -Uri "https://$AppVolServer/cv_api/manager_services"



#______________________________________________________________________________________

# Settings



# Get - Settings

Invoke-RestMethod -WebSession $SourceServerSession -Method Get -Uri "https://$AppVolServer/cv_api/settings"

# Settings can be a bit hidden properties in this, as as you go through the nested properties, be sure to do a "| Get-Memeber -force" to see more of the hidden properties the lower down you go.
